2007 Toyota Camry Owner's Manual: Every Spec from Oil Type to Tire Size You Need to Know
The 2007 Toyota Camry marked the debut of the XV40 generation—a complete redesign that arrived with updated styling, more powerful engine options, and improved technology. As one of America’s best-selling sedans, understanding every specification of the 2007 Camry is essential whether you’re shopping for a used example, performing maintenance, or simply curious about what makes this midsize sedan tick.
This comprehensive guide covers every specification you need: from gas tank capacity and fuel economy to oil type, bolt patterns, tire sizes, and engine details. We’ve organized everything into easy-to-reference tables so you can quickly find the exact information you’re looking for.
2007 Toyota Camry Overview
The 2007 model year represented a significant leap forward for the Camry. Toyota moved to the XV40 platform, bringing a more sculpted exterior, a refined interior with improved materials, and two updated powertrains plus an all-new hybrid variant.
Key Highlights:
- All-new XV40 platform replacing the previous XV30 generation
- Updated 2.4L four-cylinder engine
- New 3.5L V6 replacing the previous 3.0L unit
- First Camry Hybrid introduced
- Available in CE, LE, SE, XLE, and Hybrid trims
- Improved safety features including optional stability control
2007 Toyota Camry Engine Specifications
The 2007 Camry offered three distinct powertrain options, each catering to different driving preferences and efficiency needs.
2.4L 4-Cylinder Engine (2AZ-FE)
| Specification | Value |
|---|---|
| Displacement | 2.4L (2,362 cc / 146 ci) |
| Configuration | Inline 4-cylinder |
| Valvetrain | DOHC, 16-valve with VVT-i |
| Horsepower | 158 hp @ 6,000 rpm |
| Torque | 161 lb-ft @ 4,000 rpm |
| Compression Ratio | 9.8:1 |
| Fuel Type | Regular unleaded (87 octane) |
| Engine Block Material | Aluminum |
| Cylinder Head Material | Aluminum |
The 2.4L four-cylinder was the volume seller, offering a solid balance of power and efficiency. The VVT-i (Variable Valve Timing with intelligence) system helps optimize performance across the rev range while maintaining fuel economy.
3.5L V6 Engine (2GR-FE)
| Specification | Value |
|---|---|
| Displacement | 3.5L (3,456 cc / 211 ci) |
| Configuration | V6 |
| Valvetrain | DOHC, 24-valve with Dual VVT-i |
| Horsepower | 268 hp @ 6,200 rpm |
| Torque | 248 lb-ft @ 4,700 rpm |
| Compression Ratio | 10.8:1 |
| Fuel Type | Regular unleaded (87 octane) |
| Engine Block Material | Aluminum |
| Cylinder Head Material | Aluminum |
The 3.5L V6 was a major upgrade over the previous generation’s 3.0L unit, delivering significantly more power while actually improving fuel efficiency thanks to the Dual VVT-i system and six-speed automatic transmission.
2.4L Hybrid Powertrain (2AZ-FXE)
| Specification | Value |
|---|---|
| Engine Displacement | 2.4L |
| Engine Output | 147 hp @ 6,000 rpm |
| Electric Motor Output | 40 hp (peak) |
| Combined System Output | 187 hp |
| Engine Torque | 138 lb-ft @ 4,400 rpm |
| Battery Type | Nickel-Metal Hydride (NiMH) |
| Transmission | Electronically Controlled CVT |
The 2007 Camry Hybrid was the first of its kind for the nameplate, combining the proven 2.4L engine with an electric motor for impressive fuel economy without sacrificing everyday usability.
2007 Toyota Camry Transmission Specifications
| Engine | Transmission Type | Speeds | Available With |
|---|---|---|---|
| 2.4L 4-Cylinder | Manual | 5-speed | CE, SE |
| 2.4L 4-Cylinder | Automatic | 5-speed | CE, LE, SE, XLE |
| 3.5L V6 | Automatic | 6-speed | LE, SE, XLE |
| 2.4L Hybrid | CVT | Variable | Hybrid |
The manual transmission was only available on the base CE and sport-oriented SE trims with the four-cylinder engine. The six-speed automatic with the V6 was a notable improvement, providing smoother shifts and better highway fuel economy compared to the five-speed unit.
2007 Toyota Camry Fuel Economy (MPG)
Fuel economy varies significantly depending on engine choice and transmission. Here are the official EPA ratings:
4-Cylinder Models
| Trim | Transmission | City MPG | Highway MPG | Combined MPG |
|---|---|---|---|---|
| CE | 5-speed Manual | 24 | 34 | 28 |
| CE | 5-speed Automatic | 21 | 30 | 24 |
| LE | 5-speed Automatic | 21 | 30 | 24 |
| SE | 5-speed Manual | 24 | 34 | 28 |
| SE | 5-speed Automatic | 21 | 30 | 24 |
| XLE | 5-speed Automatic | 21 | 30 | 24 |
V6 Models
| Trim | Transmission | City MPG | Highway MPG | Combined MPG |
|---|---|---|---|---|
| LE V6 | 6-speed Automatic | 22 | 31 | 25 |
| SE V6 | 6-speed Automatic | 22 | 31 | 25 |
| XLE V6 | 6-speed Automatic | 21 | 30 | 24 |
Hybrid Model
| Trim | Transmission | City MPG | Highway MPG | Combined MPG |
|---|---|---|---|---|
| Hybrid | CVT | 40 | 38 | 39 |
Real-World Observations:
- Manual transmission models consistently achieve 3-4 MPG better than automatics in city driving
- Highway fuel economy is more consistent across transmission types
- The Hybrid’s city MPG actually exceeds its highway rating—a hallmark of hybrid efficiency
- Real-world consumption typically runs 10-15% higher than EPA ratings for most drivers
- Aggressive driving can reduce fuel economy by 20-30%
2007 Toyota Camry Gas Tank Size
The fuel tank capacity varies by powertrain:
| Model | Gas Tank Capacity (Gallons) | Gas Tank Capacity (Liters) |
|---|---|---|
| Gasoline Models (All Trims) | 18.5 gal | 70.0 L |
| Hybrid Model | 17.1 gal | 64.7 L |
Fuel Range Estimates:
| Model | City Range | Highway Range |
|---|---|---|
| 4-Cylinder Automatic | ~389 miles | ~555 miles |
| 4-Cylinder Manual | ~444 miles | ~629 miles |
| V6 | ~407 miles | ~574 miles |
| Hybrid | ~684 miles | ~650 miles |
The Hybrid’s smaller fuel tank is offset by its dramatically better fuel economy, resulting in the longest range of any 2007 Camry variant.
2007 Toyota Camry Oil Type and Capacity
Using the correct oil is crucial for engine longevity. Here are the specifications:
Oil Specifications by Engine
| Engine | Recommended Oil | Oil Capacity (With Filter) | Oil Filter Part Number |
|---|---|---|---|
| 2.4L 4-Cylinder | SAE 5W-30 | 4.0 quarts (3.8 L) | Toyota 04152-YZZA1 or equivalent |
| 3.5L V6 | SAE 5W-30 | 6.0 quarts (5.7 L) | Toyota 90915-YZZD4 or equivalent |
| 2.4L Hybrid | SAE 5W-30 | 4.4 quarts (4.2 L) | Toyota 04152-YZZA1 or equivalent |
Oil Type Details
SAE 5W-30 is the factory-specified oil for all 2007 Camry engines. This multi-viscosity oil provides:
- Excellent cold-weather starting protection (5W)
- Proper high-temperature protection (30 weight)
- Good fuel economy compared to heavier oils
- Adequate protection for the operating tolerances of these engines
Can You Use 0W-20? Some owners and shops use 0W-20 in the 2.4L engine, especially in colder climates. While Toyota’s official specification for 2007 models is 5W-30, 0W-20 is generally acceptable and may slightly improve cold-weather fuel economy. However, 5W-30 remains the manufacturer-recommended choice.
Oil Change Intervals:
- Normal driving conditions: Every 5,000 miles or 6 months
- Severe conditions (frequent short trips, dusty roads, extreme temperatures): Every 3,000 miles or 3 months
Severe conditions include:
- Repeated short trips (less than 5 miles)
- Stop-and-go traffic
- Extreme heat or cold
- Dusty environments
- Towing or mountain driving
2007 Toyota Camry Bolt Pattern and Wheel Specifications
Understanding wheel specifications is essential for replacement or upgrade purposes.
Bolt Pattern (PCD)
| Specification | Value |
|---|---|
| Bolt Pattern | 5x114.3mm (5x4.5 inches) |
| Thread Size | M12 x 1.5 |
| Center Bore | 60.1mm |
| Lug Nut Type | Conical (tapered) seat |
| Lug Nut Torque | 76 ft-lbs (103 Nm) |
The 5x114.3mm bolt pattern is one of the most common in the automotive world, making wheel selection plentiful. Compatible vehicles include many Toyota, Honda, Nissan, Mazda, and Ford models.
Wheel Specifications by Trim
| Trim | Wheel Size | Wheel Material | Offset (ET) | Tire Size |
|---|---|---|---|---|
| CE | 16 x 6.5 inches | Steel with cover | +45mm | P215/60R16 |
| LE | 16 x 6.5 inches | Steel with cover | +45mm | P215/60R16 |
| SE | 17 x 7.0 inches | Aluminum alloy | +35mm | P215/55R17 |
| XLE | 16 x 6.5 inches | Aluminum alloy | +45mm | P215/60R16 |
| Hybrid | 16 x 6.5 inches | Aluminum alloy | +45mm | P215/60R16 |
2007 Toyota Camry Tire Size Guide
Standard Tire Sizes
| Trim | Tire Size | Tire Diameter | Section Width | Aspect Ratio |
|---|---|---|---|---|
| CE, LE, XLE, Hybrid | P215/60R16 | 26.1 inches | 215mm | 60% |
| SE | P215/55R17 | 26.3 inches | 215mm | 55% |
Alternative/Upgrade Tire Sizes
| Size | Type | Notes |
|---|---|---|
| 215/60R16 | Stock (most trims) | Factory standard, optimal comfort |
| 215/55R17 | Stock (SE) / Upgrade | Sportier appearance, slightly lower profile |
| 225/50R17 | Upgrade | Wider contact patch, may affect speedometer |
| 225/45R18 | Upgrade | Aggressive look, stiffer ride |
| 225/40R19 | Upgrade (with clearance check) | Maximum visual impact, reduced comfort |
Tire Pressure Specifications:
- Front: 32 psi (220 kPa)
- Rear: 32 psi (220 kPa)
- Spare: 60 psi (420 kPa) for compact spare
Spare Tire: All 2007 Camry models come with a compact spare tire (T-type) located in the trunk. The compact spare is for temporary use only and should not be driven at speeds exceeding 50 mph.
2007 Toyota Camry Dimensions
Exterior Dimensions
| Dimension | Measurement |
|---|---|
| Overall Length | 189.2 inches (4,806 mm) |
| Overall Width | 71.7 inches (1,821 mm) |
| Overall Height | 57.9 inches (1,471 mm) |
| Wheelbase | 109.3 inches (2,776 mm) |
| Front Track | 62.0 inches (1,575 mm) |
| Rear Track | 61.6 inches (1,565 mm) |
| Ground Clearance | 5.3-5.5 inches (135-140 mm) |
| Turning Diameter | 36.1 feet (11.0 m) |
Interior Dimensions
| Dimension | Front | Rear |
|---|---|---|
| Headroom | 38.8 inches | 37.8 inches |
| Legroom | 41.7 inches | 38.3 inches |
| Shoulder Room | 57.8 inches | 56.9 inches |
| Hip Room | 54.6 inches | 53.9 inches |
| Passenger Volume | 101.4 cu ft | — |
Cargo Capacity
| Model | Trunk Volume |
|---|---|
| Gasoline Models | 14.5-15.0 cu ft |
| Hybrid | 10.6 cu ft |
The Hybrid’s reduced trunk capacity is due to the nickel-metal hydride battery pack located behind the rear seats.
2007 Toyota Camry Weight Specifications
| Model | Curb Weight |
|---|---|
| CE 4-Cylinder (Manual) | 3,285 lbs (1,490 kg) |
| LE 4-Cylinder (Automatic) | 3,307 lbs (1,500 kg) |
| SE 4-Cylinder | 3,330 lbs (1,510 kg) |
| XLE 4-Cylinder | 3,340 lbs (1,515 kg) |
| LE V6 | 3,450 lbs (1,565 kg) |
| SE V6 | 3,460 lbs (1,569 kg) |
| XLE V6 | 3,516 lbs (1,595 kg) |
| Hybrid | 3,637 lbs (1,650 kg) |
The Hybrid is the heaviest model due to the additional weight of the electric motor, power electronics, and battery pack.
2007 Toyota Camry Brake Specifications
| Specification | Front | Rear |
|---|---|---|
| Brake Type | Ventilated disc | Solid disc |
| Rotor Diameter | 11.65 inches (296 mm) | 11.02 inches (280 mm) |
| Rotor Thickness (New) | 1.10 inches (28.0 mm) | 0.43 inches (10.0 mm) |
| Minimum Thickness | 1.02 inches (26.0 mm) | 0.35 inches (9.0 mm) |
| Brake Pad Thickness (New) | 0.47 inches (12.0 mm) | 0.39 inches (10.0 mm) |
| ABS | Standard | Standard |
2007 Toyota Camry Suspension Specifications
| Component | Type |
|---|---|
| Front | MacPherson strut with stabilizer bar |
| Rear | Dual-link with coil springs and stabilizer bar |
| Front Stabilizer Bar | 0.95 inches (24mm) |
| Steering | Electric power-assisted rack-and-pinion |
The SE trim received sport-tuned suspension with stiffer springs and dampers for improved handling dynamics.
2007 Toyota Camry Trim Level Comparison
Base Features by Trim
| Feature | CE | LE | SE | XLE | Hybrid |
|---|---|---|---|---|---|
| Engine | 2.4L | 2.4L or 3.5L | 2.4L or 3.5L | 2.4L or 3.5L | 2.4L Hybrid |
| Air Conditioning | Manual | Auto | Auto | Dual-Zone | Dual-Zone |
| Power Windows | Yes | Yes | Yes | Yes | Yes |
| Power Locks | Yes | Yes | Yes | Yes | Yes |
| Keyless Entry | No | Yes | Yes | Yes | Yes |
| Cruise Control | Yes | Yes | Yes | Yes | Yes |
| Audio System | AM/FM/CD | AM/FM/CD | AM/FM/CD | JBL Premium | JBL Premium |
| Bluetooth | No | Optional | Optional | Yes | Yes |
| Navigation | No | Optional | Optional | Optional | Optional |
| Alloy Wheels | No | No | Yes (17”) | Yes (16”) | Yes (16”) |
| Fog Lights | No | No | Yes | Yes | Yes |
| Rear Spoiler | No | No | Yes | No | No |
| Paddle Shifters | No | No | Yes (Auto) | No | No |
| Sport Suspension | No | No | Yes | No | No |
2007 Toyota Camry Safety Specifications
Standard Safety Features
| Feature | Availability |
|---|---|
| Dual Front Airbags | Standard |
| Front Side Airbags | Standard |
| Front and Rear Side Curtain Airbags | Standard |
| Driver Knee Airbag | Standard |
| 4-Wheel ABS | Standard |
| Electronic Brakeforce Distribution | Standard |
| Brake Assist | Standard |
| Tire Pressure Monitoring System | Standard |
| Daytime Running Lights | Standard |
Optional Safety Features
| Feature | Availability |
|---|---|
| Vehicle Stability Control (VSC) | Optional |
| Traction Control (TRAC) | Optional |
| Active Headrests | Standard on all trims |
2007 Toyota Camry Maintenance Schedule
Recommended Service Intervals
| Service Item | Interval | Notes |
|---|---|---|
| Engine Oil & Filter | 5,000 miles or 6 months | Use SAE 5W-30 |
| Tire Rotation | 5,000-7,500 miles | Alternate front/rear |
| Brake Inspection | Every 15,000 miles | Check pads and rotors |
| Transmission Fluid | 60,000 miles | Or as indicated by vehicle |
| Coolant | 100,000 miles or 10 years | First replacement, then every 50,000 miles |
| Spark Plugs | 120,000 miles | Iridium plugs standard |
| Drive Belt | 60,000 miles | Inspect at each service |
| Cabin Air Filter | 15,000-30,000 miles | Replace if airflow decreases |
2007 Toyota Camry Common Specifications Issues
While the 2007 Camry is generally reliable, here are specifications-related items to watch:
-
Oil Consumption (2.4L Engine): Some 2AZ-FE engines may consume more oil as they age. Monitor oil levels between changes and top off as needed.
-
Transmission Programming: The five-speed automatic can develop harsh shifts at higher mileage. Regular fluid changes help maintain shift quality.
-
Water Pump Weep Hole: The 3.5L V6 water pump may develop a leak from the weep hole around 80,000-100,000 miles.
-
Dashboard Material: Some 2007 models experienced dashboard material degradation in hot climates.
2007 Toyota Camry Frequently Asked Questions
What is the gas tank size for a 2007 Toyota Camry?
The 2007 Camry has an 18.5-gallon (70.0 L) fuel tank for gasoline models and a 17.1-gallon (64.7 L) tank for the Hybrid.
What type of oil does a 2007 Toyota Camry take?
The 2007 Camry uses SAE 5W-30 motor oil for all engine variants. The 4-cylinder holds 4.0 quarts and the V6 holds 6.0 quarts with filter.
What is the MPG for a 2007 Toyota Camry?
Fuel economy ranges from 21-24 city / 30-34 highway MPG for gasoline models, while the Hybrid achieves 40 city / 38 highway MPG.
What is the bolt pattern on a 2007 Toyota Camry?
The bolt pattern is 5x114.3mm (5x4.5 inches) with M12 x 1.5 thread size.
What tire size comes on a 2007 Toyota Camry?
Most trims use P215/60R16 tires, while the SE trim uses P215/55R17 tires.
How much horsepower does a 2007 Toyota Camry have?
The 2.4L four-cylinder produces 158 hp, the 3.5L V6 produces 268 hp, and the Hybrid produces 187 hp combined.
What are the dimensions of a 2007 Toyota Camry?
The 2007 Camry measures 189.2” L x 71.7” W x 57.9” H with a 109.3-inch wheelbase.
How much does a 2007 Toyota Camry weigh?
Curb weight ranges from 3,285 lbs for the base CE to 3,637 lbs for the Hybrid.
Conclusion
The 2007 Toyota Camry remains a benchmark for midsize sedan specifications, offering a comprehensive range of powertrains, trims, and features to suit virtually any buyer’s needs. Whether you’re drawn to the efficiency of the Hybrid, the power of the V6, or the value of the four-cylinder models, understanding these specifications helps you make informed decisions about maintenance, upgrades, and daily ownership.
With its proven reliability, excellent fuel economy, and straightforward maintenance requirements, the 2007 Camry continues to be a smart choice in the used car market nearly two decades after its introduction.
All specifications are based on factory data for the US market. Specifications may vary for other markets. Always consult your owner’s manual or a qualified technician for vehicle-specific information.
